For: Sachs

34381

Repair instructions | Sachs 50/3 ML, MLK, LKH, LH

rating iconrating iconrating iconrating iconrating icon
No reviews
EUR 36.80

Incl. 25.5% VAT.

Description

Nostalgic repair manual with detailed descriptions for repairing your Sachs 50/3, 50/3 ML, 50/3 MLK etc. Moped / moped engine.

All aspects of the engine are described in detail and are illustrated by comprehensive revision instructions, numerous pictures and important facts.
In addition, the following areas are explained in detail: technical data, special tools, engine, inspection work, carburetor and the ignition system.

MaterialPaper
DIN formatA5
Number of pages64 pcs
LanguageGerman
Sachs

50/3
