Motor cable routing | Z50

swiing® revival cable guide mudguard black | Puch

Manufacturer: swiing® revival parts · Material: Plastic · Color: black · Total length: 74 mm · Height: 12.5 mm · Hole spacing: 63 mm · Mounting type: Plug connection · Number of fixing points: 2 pcs

swiing® revival gasket set Z50 engine | Puch X30 NS / NL

Manufacturer: swiing® revival parts · Material: Sealing paper · Area of application: Standard · Ø outlet inside: 22 mm · Hole spacing inlet: 32 - 38 mm · Number of components: 10 pcs · Hole pattern [mm]: 44 x 44 · Hole spacing outlet: 42 mm

Oil filler plug with sealing ring | Puch E50

Material: Steel · Surface: galvanized (blue) · Thread type: M10x1.5 (standard thread) · Total length: 14.6 mm · Drive: Slot · Screw head: Lens head · Ø External head: 14 mm · Number of components: 2 pcs · Thread length: 6 mm · Puch OEM number: 364.1.10.660.1

Tank cap lockable high version | Puch Maxi S, N

Material: Plastic · Lockable: Yes · Color: black · Fuel filler cap: Plug 30 mm

GPO gasket cylinder base 0.35 mm original | Puch

Nominal diameter: 47 mm · Manufacturer: GPO · Material: Oiled paper · Area of application: Standard · Ø inside: 47 mm · Place of use: Cylinder base · Thickness: 0.3 mm · Hole pattern [mm]: 44 x 44 · Puch OEM number: 349.3.10.013.1

swiing® revival gearbox cover gasket (old model) | Puch Z50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Total length: 166 mm · Thickness: 0.35 mm · Width: 155 mm · Number of components: 1 pcs · Number of fixing points: 8 pcs

Bride cable original | Piaggio SI

Manufacturer: Piaggio · Ø mounting hole: 7.15 mm

Petrol hose Ø 5 / 7 mm transparent 30 cm

Manufacturer: Made in Italy · Color: transparent · Ø inside: 5 mm · Ø outside: 7 mm · Total length: 300 mm

Cable routing Bowden cable

Material: Aluminum · Ø inside: 0 - 8 mm · Width: 20.5 mm
