Gilardoni italkit 4-folding diaphragm original

Gilardoni italkit 47 mm cylinder kit without cylinder head | Puch

Manufacturer: Gilardoni italkit · Material: Aluminum · Camouflaged: No · Crankshaft stroke: 43 mm · Displacement: 75 ccm · Surface: sandblasted · Nominal diameter: 47 mm · Ø cylinder neck: 51 mm · Ø outlet inside: 26.5 mm · Ø Inlet inside: 18.3 mm · Hole spacing inlet: 35.5 mm · Hole spacing inlet: 60 mm · Ø piston pin (B): 12 mm · Inlet window: 38.5 x 25.8 · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Outlet type: slanted · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning · Decompressor: No

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Mounting type: Union nut · Installation direction: horizontal / horizontal · Thread type: MF12x1 (fine pitch thread) · Outlet direction: below · Spare tube shape: curved · Ø fuel hose connection: 6 mm · Reserve level: 70 mm

Gilardoni italkit seal kit 47 mm

Manufacturer: Gilardoni italkit · Ø cylinder: 47 mm · Number of components: 5 pcs · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 mm / 60 x 35 mm · Area of application: Tuning

swiing® revival nozzle set M5 (70 - 92) Dell'Orto SHA, PHBG

Drive: Slot · Manufacturer: swiing® revival parts · Component group Carburetor: Spraying · Material: Brass · Quantity: 10 pcs · Carburetor type: PHBG · Carburetor type: SHA · Carburetor type: SHA (Piaggio) · Nozzle type: Main nozzle · Total length: 8 mm · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 70 · Nozzle size: 72 · Nozzle size: 75 · Nozzle size: 78 · Nozzle size: 80 · Nozzle size: 82 · Nozzle size: 85 · Nozzle size: 88 · Nozzle size: 90 · Nozzle size: 92

DMP intake rubber Ø 33.5 / 33.5 x 31.5 with clamps

Manufacturer: DMP · Material: Rubber · Overall length (A): 31.3 mm · Color: black · Ø Passage (B): 30.7 mm · Ø inside (C): 33.5 mm · Ø inside 2 (D): 33.5 mm · Ø outside (E): 46.5 mm · Ø outside 2 (F): 46.5 mm · Ø External connection (G): 46.5 mm · Ø External connection 2 (H): 46.5 mm · Ø Clamping (I): 32.5 mm · Ø Clamping 2 (K): 32.5 mm

Gilardoni italkit piston 47 mm #A | Puch

Manufacturer: Gilardoni italkit · Ø outside piston (A): 46.96 mm · Compression height (C): 22.5 mm · Curvature (D): 3.2 mm · Total piston height (E): 52.5 mm · Number of piston rings (F): 2 pcs · Nominal diameter: 47 mm · Piston ring mold: L-ring · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Piston ring height: 2 mm · Ø piston pin (B): 12 mm · Tolerance group: A · Piston weight: 100 g

Intake manifold set Gilardoni italkit 24 mm

Ø inside: 24 mm · Mounting type: Screws · Ø External connection: 31 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 35 · Area of application: Tuning

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom | Puch Maxi S, N

Possible lever positions: open / closed / reserve · Material lever: Aluminum · Filter type: Plastic net · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Thread type: MF12x1 (fine pitch thread) · Ø fuel hose connection: 6 mm · Reserve level: 70 mm · Mounting type: Union nut · Puch OEM number: 349.3.22.030.0 · Puch OEM number: 349.4.22.030.0

MLM exhaust DaVinci slanted outlet | Puch

Manufacturer: MLM · Material: Steel · Color: black · Flame tube attachment: Flange · Mounting type: Welded lug · Exhaust type: Cone / double cone

NGK CR4 Racing ignition cable & plug High End red

Manufacturer: NGK · Material: Silicone · Color: red · Cable length: 500 mm · Spark plug socket: SAE · Cable available: Yes · Suppressed: Yes · Resistance: 5000 Ω · Component group Carburetor: Ignition cable · Component group Carburetor: Spark plug connector · Ø cable: 7 mm
