Corteco oil seal set transmission Vario & torque converter | Piaggio Ciao, SI, Bravo, Boxer

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Manufacturer: GPO · Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Thread type: MF12x1 (fine pitch thread) · Installation direction: horizontal / horizontal · Outlet direction: below · Mounting type: Union nut · Spare tube shape: curved · Ø fuel hose connection: 6 mm · Reserve level: 70 mm

M8 sealing ring Fiber

Material: Fiber · Surface: raw · Place of use: Carburetor · Place of use: Motor housing · Ø outside: 13.7 mm · Thickness: 1 mm · Ø inside: 8.3 mm · Area of application: Standard · Puch OEM number: 26482

Pedals square | Piaggio Ciao, SI, Bravo

Material: Plastic · Surface: ribbed · Color: black · Width: 51 mm · Drive: Outer edge · Height: 29 mm · Thread type: FG14.3 (9/16" 20G) · Width across flats: 15 mm · Total length: 118 mm · Reflectors: Yes

Malossi air filter | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Malossi · Material: Plastic · Color: black · Filter type: Foam · Width: 95 mm · Ø outside: 53.2 mm · Height: 88.7 mm · Ø Internal connection: 51 mm · Total length: 31.2 mm · Mounting type: Plug connection clamped · Area of application: Tuning · Camouflaged: No

CIF locking plate clutch Vario | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: CIF

Oil seal NBR 20/30/5 A Gearbox original | Piaggio Ciao, SI, Bravo, Boxer

Shaft seal type: A - With rubberized outer part / one sealing lip. · Manufacturer: Piaggio · Material: NBR · Width: 5 mm · Ø outside: 30 mm · Ø inside: 20 mm · Temperature resistance (min.): -30 - 100 °C

GPO oil seal set engine & gearbox (mono) | Piaggio Ciao, SI, Bravo, Boxer

Shaft seal type: A - With rubberized outer part / one sealing lip. · Shaft seal type: B - With sheet metal outer casing / one sealing lip. · Manufacturer: GPO · Material: NBR · Place of use: Clutch · Place of use: Crankshaft · Place of use: Gear hub · Place of use: Gearbox cover · Width: 3 mm · Width: 4 mm · Width: 5 mm · Ø outside: 22 mm · Ø outside: 24 mm · Ø outside: 25 mm · Ø outside: 30 mm · Ø inside: 15 mm · Ø inside: 16 mm · Ø inside: 17 mm · Ø inside: 20 mm · Area of application: Original · Temperature resistance (min.): -30 - 120 °C

Oil seal 13/22/4 A NBR gearbox Vario original | Piaggio Ciao, SI, Bravo, Boxer

Shaft seal type: A - With rubberized outer part / one sealing lip. · Manufacturer: Piaggio · Material: NBR · Width: 4 mm · Ø outside: 22 mm · Ø inside: 13 mm · Temperature resistance (min.): -30 - 100 °C · Piaggio OEM number: 240222

swiing® revival gasket gearbox | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: swiing® revival parts · Material: Oiled paper · Gearbox type: Mono · Gearbox type: Vario · Place of use: Gearbox cover · Thickness: 0.3 mm · Piaggio OEM number: 482552
