Repair manual for Puch X30 models.
This great catalog with 52 pages contains a lot of interesting facts about the X30. Many repairs are described.
The 2-speed manual engine is described with revision instructions, many pictures and important facts.
The following things are also described extensively: special tools, engine, inspection work, carburetor, frame, front fork, brakes, wheels, behavior in the event of malfunctions, maintenance, overhaul work and the electrical system.
I advise every Puch fan/wrench to read a book like this, you can always learn something new.
Bilingual; German and French.
| Material | Paper |
| Number of pages | 52 pcs |
| Language | German, French |
| Puch | Z50 (X30 Velux) |
