Dell'Orto carburetor cover SHA 7 - 13 mm

BERU spark plug connector / 1 kΩ interference suppressed

Manufacturer: BERU · Color: silver · Material: Sheet metal (steel) · Ø cable: 5 mm · Ø cable: 7 mm · Spark plug socket: M4 · Cable available: No · Suppressed: Yes · Resistance: 1000 Ω · Component group Carburetor: Spark plug connector · Pony OEM number: A2099 · Sachs OEM no.: 0265 100 00

Gas cable Ø 1.2 mm x 165 cm (nipple ball) Dell'Orto

Manufacturer: Made in Germany · Ø nipple: 3.5 mm · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Ø Stranded wire: 1.2 mm · Cable length: 1650 mm · Nipple shape: Ball

Dell'Orto 90° carburetor pipe bend set M6x0.75

Manufacturer: Dell'Orto · Width across flats nut: 7 mm · Material: Brass · Component group Carburetor: Adjusting screws, float, etc. · Thread type: MF6x0.75 (fine pitch thread) · Height: 27 mm · Total length: 43 mm · Total length: 52 mm · Surface: nickel-plated · Ø outside: 6 mm · Internal thread: MF5x0.75 (fine pitch thread) · Angle: 90 °

CIF intermediate disk flywheel / clutch bell | Piaggio Ciao, SI, Bravo Boxer

Manufacturer: CIF · Material: Steel · Surface: galvanized (blue) · Nominal diameter inside: 12 mm · Ø outside: 23 mm · Total length: 5 mm · Ø inside: 12 mm · Ø Bundle: 16.3 mm

Dell'Orto reducing bush SHA 12mm (16/18 mm)

Manufacturer: Dell'Orto · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Carburetor type: SHA · Carburetor type: SHA (Piaggio) · Ø inside: 16 mm · Ø Passage: 12 mm · Ø outside: 18 mm · Total length: 14 mm · Color: white · Piaggio OEM number: 114482

90° carburetor pipe bend M6x0.75 Dell'Orto SHA original | Piaggio Ciao

Manufacturer: Piaggio · Material: Brass · Component group Carburetor: Adjusting screws, float, etc. · Surface: nickel-plated · Angle: 90 ° · Thread type: MF6x0.75 (fine pitch thread) · Ø outside: 6 mm · Total length: 27.5 mm · Internal thread: MF5x0.75 (fine pitch thread) · Height: 30 mm

Dell'Orto throttle slide #6 SHA 7 - 13 mm

Nipple shape: Ball · Manufacturer: Dell'Orto · Material: Aluminum · Component group Carburetor: Adjusting screws, float, etc. · Carburetor type: SHA (Piaggio) · Width: 15.8 mm · Slider type: 6 · Height: 26.3 mm · Thickness: 3 mm

Dell'Orto slide spring SHA 7 - 13 mm

Spring design: Pressure spring · Manufacturer: Dell'Orto · Carburetor type: SHA (Piaggio) · Total length: 28 mm · Ø outside: 10.5 mm

Dell'Orto reducing bush SHA 13 mm (16/18mm)

Manufacturer: Dell'Orto · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Color: white · Carburetor type: SHA (Piaggio) · Ø outside: 18 mm · Ø inside: 16 mm · Ø Passage: 13.3 mm · Total length: 14 mm

Cover gasket 13/11 SHA Spaco carburetor original | Beta 521

Manufacturer: Pony · Material: Sealing paper · Component group Carburetor: Sealing, revising · Carburetor type: SHA · Thickness: 0.4 mm
